Make :DHIM, South Korea
Material: CRCA/HRPO/SS/GAL
Material Strength (Tensile):Max 990 Mpa (3.0 × 1,240) & 460 MPa (3.2×1,830)
Thickness : 0.35 - 3.2 mm)
Input Max Width : 1,830 mm
Length range : : 400 - 4,500 mm
Flatness tolerance : 2 IU max
Length tolerance : +/- 0.25mm
Diagonal difference :Within 0.30mm (up to 1.5mX 2m) Within 0.40mm up to max size
Burr : 2% of strip thickness or 20 microns, whichever is less
Line Speed :80 m / min
Production Capacity :1,27,000 tons per year

6 Hi leveler for achieving flatness of up to 2 IU max

Trapezoidal cutting angle of up to 40˚

Close length tolerance of up to 0.25 mm

Servo control system supplied by NUSCO, Japan

Magnetic piler for scratch free stacking

Capable of shearing materials up to TS of 990 MPa
