Specifications
Make : DHIM, South Korea
Material: CRCA/HRPO/SS/GAL
Material Strength (Tensile):900MPa max
Input Width : 1850mm Max
Input Thickness : 0.35-3.2mm
Output Coil width : 45mm to 1850mm
Line Speed : 300m/min Max
Production Capacity 1,27,000 tons per year
Camber :Within 0.3mm per length 2,000mm
Edge Burr
| Thickness range (mm) | Height of edge Burr |
|---|---|
| 0.35 – 0.59 | Max. 4 % of strip thickness |
| 0.6 – 3.2 | Max. 2 % of strip thickness |
Width Tolerance
| Thickness | Under 160 | 160 ~ 250 | 250 ~ 400 | 400 ~ 630 | Over 600 |
|---|---|---|---|---|---|
| Under 0.5 | ± 0.05 | ± 0.08 | ± 0.08 | ± 0.08 | ± 0.1 |
| 0.6 – 3.2 | ± 0.08 | ± 0.1 | ± 0.1 | ± 0.1 | ± 0.1 |
Unique features
